庫卡機器人通用型KR210 R2700 extra

Technical data
Maximum reach 2696 mm
Rated payload 210 kg
Rated supplementary load, rotating column /
link arm / arm
0 kg / 0 kg / 50 kg
Rated total load 260 kg
Pose repeatability (ISO 9283) ± 0.06 mm
Number of axes 6
Mounting position Floor
Footprint 830 mm x 830 mm
Weight approx. 1068 kg
Axis data
Motion range
A1 ±185 °
A2 -140 ° / -5 °
A3 -120 ° / 155 °
A4 ±350 °
A5 ±125 °
A6 ±350 °
Speed with rated payload
A1 123 °/s
A2 115 °/s
A3 112 °/s
A4 179 °/s
A5 172 °/s
A6 219 °/s
